Electro Voice RE90B Omnidirectional Condenser Boundary Microphone - Black

Buy risk free with our 14 day - full refund, less shipping, return policy. Check out our shop policies for more details.

Description
The Electro-Voice RE90B and RE90BW are part of the Architectural Microphone Series. The RE90B is a full-range condenser microphone designed to be used for surface mounted applications such as distance learning centers, video conferencing systems, teleconferencing systems, and sound reinforcements (see Figure 1). The polar pattern of the RE90B is half-cardioid (half-space cardioid) to promote good gain-be-fore- feedback and suppress ambient noise. All boundary type microphones operated on a flat surface are subject to an increase in sensitivity of the microphone with increasing frequency; this is called the baffle effect. To counteract this effect, the RE90B has been designed with internal equalization to give the RE90B a flat sensitivity response. The RE90B is designed to be powered by an external 9-52 V dc phantom power supply (DIN 45 596). The RE90B microphone is encased in a heavy-duty zinc die cast body protected by a strong, perforated steel screen. The body of the microphone is designed to provide two d

Product Identifiers

• Brand: Electro-Voice
• Model: RE-90B
• MPN: re90bw
• UPC: 701001013746, 701001013753

Key Features

• Connectivity Cable
• Consumer Compatibility Business / Office
• Professional Compatibility Installed, Video Filming
• Sound Mode Mono
• Type Condenser Microphone
• Usage Consumer

Technical Features

• Impedance: 200 ohms
• Directivity: Cardioid
• Frequency Response: 80 - 15000 Hz

Plug

• Plug Type: XLR

Other Features

• Built In On/Off Switch Without On/Off Switch
• Cable Length 6 ft.

Dimensions

• Weight 6.1 oz
